Rated Power: 522 kW @ 1500RPM
Fuel Pump: BYC PD Pump
Governor: GAC Elec.
Aspiration: TC &Charge Air Cooled
Emission Standard: N/A
DCEC 6ZTAA13 Generator Drive Engine
DCEC 6ZTAA13 series generator drive engine is a 6-cylinders in line,13 liter four-strokes engine with 130 mm bore and 163 mm stroke. DCEC 6ZTAA13 series generator drive engine equipped with BYC fuel pump and provides both mechanical governor and electronic governor for customers to choose from.
The prime power range for 50 Hz generator set (1500 RPM) of DCEC 6ZTAA13 series generator drive engine is from 340 kW to 400 kW. The prime power range for 60 Hz generator set (1800 RPM) of DCEC 6ZTAA13 series generator drive engine is from 340 kW to 400 kW.
DCEC generator drive engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. As part of EMAC, SinoGen also provide complete power supply solutions that powered by DCEC, our ranges of products including open type generator set, silence type generator set, super silence type generator set, mobile trailer, complete power truck and complete power car for railways applications. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
General Specifications of 6LTAA8.9 Series
| Engine Type: | 6 Cylinders |
| Displacement: | 8.9 L |
| Rated Speed: | 1500 – 1800 RPM |
| Aspiration Method: | Turbocharged & Air-Air Intercooler |
| Prime Power: | 220 – 255 kW @ 1500 – 1800 RPM |
| Fuel System: | Direct injection |
| Emission Standard: | Euro III |
| Wet Weight: | 432 kg |
| Bore * Stroke: | 102 mm * 120 mm |
| Packing Size(L * W * H): | 1080 mm * 625 mm * 1085 mm |
| DCEC 6ZTAA13 G – Drive Engine Catalogue | |||||||
Engine Model |
Prime Power |
Governor Type |
Engine Model |
Prime Power |
Governor Type |
||
| 6ZTAA13-G2-A | 522 kW @ 1500 RPM | GAC Electronic Governor | 6ZTAA13-G2-B | 522 kW @ 1800 RPM | GAC Electronic Governor | ||
| 6ZTAA13-G3-A | 455 kW @ 1500 RPM | GAC Electronic Governor | 6ZTAA13-G3-B | 455 kW @ 1800 RPM | GAC Electronic Governor | ||
| 6ZTAA13-G4-A | 537 kW @ 1500 RPM | GAC Electronic Governor | 6ZTAA13-G4-B | 537 kW @ 1800 RPM | GAC Electronic Governor | ||
| ——END—— | |||||||
DCEC 6ZTAA13 Series G-drive Engine
All models of DCEC 6ZTAA13 Series G-drive Engine.
Click here to find G-drive engines by type (Fuel System & Engine Speed).
6ZTAA13-G2-B G-Drive Engine
Rated Power: 522 kW @ 1500RPM
Fuel Pump:BYC PD Pump
Governor: GAC Elec.
Aspiration: Turbocharged & Air-Air Intercooler
Emission Standard: N/A
6ZTAA13-G3-A G-Drive Engine
Rated Power: 455 kW @ 1500RPM
Fuel Pump: BYC PD Pump
Governor: GAC Elec.
Aspiration: TC &Charge Air Cooled
Emission Standard: N/A
6ZTAA13-G3-B G-Drive Engine
Rated Power: 455 kW @ 1800RPM
Fuel Pump:BYC PD Pump
Governor: GAC Elec.
Aspiration: Turbocharged & Air-Air Intercooler
Emission Standard: N/A
6ZTAA13-G4-A G-Drive Engine
Rated Power: 537 kW @ 1500RPM
Fuel Pump: BYC PD Pump
Governor: GAC Elec.
Aspiration: TC &Charge Air Cooled
Emission Standard: N/A
6ZTAA13-G4-B G-Drive Engine
Rated Power: 537 kW @ 1800RPM
Fuel Pump:BYC PD Pump
Governor: GAC Elec.
Aspiration: Turbocharged & Air-Air Intercooler
Emission Standard: N/A
