DCEC 6CTA8.3 Marine Main Engine
DCEC 6CTA8.3 series marine main engine is a 6-cylinders in line, 8.3 liters four-strokes engine with 114 mm bore and 135 mm stroke. DCEC 6CTA8.3 series marine main engine equipped with Weifu (or BYC) fuel pump. The prime power range of DCEC 6CTA8.3 series marine main engine is from 188 HP to 260 HP.
DCEC marine main engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. Based on standard DCEC marine main engines, SeaMac provides both heat exchanger cooling and keel cooling marine main engines, we also provide complete propulsion system that including marine engine, gearbox, shaft, propeller as complete power system. SeaMac provides full life cycle services for all our customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support. All of DCEC marine main engine are comes with dry type exhaust system, which means dry type exhaust manifold and dry type turbocharger, SeaMac provides upgrading services for water-cooled exhaust system, which modify dry type exhaust system into water-cooled exhaust system, which are quite important and often requested by passenger boat projects.
General Specifications of 6CTA8.3 Series
| Engine Type: | 6 Cylinders |
| Displacement: | 8.3 L |
| Bore * Stroke: | 114 mm * 135 mm |
| Advertised Power: | 188 – 260 HP @ 1500 – 2328 RPM |
| Peak Torque: | 732 – 1125 N.m @ 1400 – 1500 RPM |
| Rated Speed: | 1500 – 2400 RPM |
| Emissision: | Euro II |
| Aspiration Method: | Turbocharged & Air-Air Intercooler |
| Wet Weight: | 604 – 637 kg |
| Dimission Standards: | 1494 mm * 796 mm * 1228mm |
Engine Model |
Rated Power |
Peak Torque |
Engine Model |
Rated Power |
Peak Torque |
||
| 6CTA8.3-M188 | 188 Hp @ 2328 RPM | 732 N.m @ 1500 RPM | 6CTA8.3-M205 | 205 Hp @ 2328 RPM | 828 N.m @ 1500 RPM | ||
| 6CTA8.3-M220 | 220 Hp @ 1800 RPM | 1000 N.m @ 1500 RPM | 6CTAA8.3-M260 | 254 HP @ 2134 RPM | 1125 N.m @ 1400 RPM | ||
| ——END—— | |||||||
DCEC 6CTA8.3 Series Marine Main Engine
This list including all models of DCEC 6CTA8.3 Series Marine Main Engine.
Click here to find marine engines by type (Fuel System & Power Range).
6CTA8.3-M188 Marine Engine
Rated Power: 188 Hp @ 2328 RPM
Max. Torque: 732 N.m @ 1500 RPM
Fuel Pump: BYC PB Pump
Governor: R801 Mech.
Aspiration: TC & Water-Air Intercooler
6CTA8.3-M205 Marine Engine
Rated Power: 205 Hp @ 2328 RPM
Max. Torque: 828 N.m @ 1500 RPM
Fuel Pump: BYC PB Pump
Governor: R801 Mech.
Aspiration: TC & Water-Air Intercooler
6CTA8.3-M220 Marine Engine
Rated Power: 220 Hp @ 1800 RPM
Max. Torque: 1000 N.m @ 1500 RPM
Fuel Pump: BYC PB Pump
Governor: RSV Mech.
Aspiration: TC & Water-Air Intercooler
6CTAA8.3-M260 Marine Engine
Rated Power: 254 HP @ 2134 RPM
Max. Torque:1125 N.m @ 1400 RPM
Fuel Pump: Weifu PW2000 Pump
Governor: RQV-K Mech.
Aspiration: TC & Air-Air Intercooler
