DCEC QSZ14 Industrial Engine
DCEC QSZ14 series Industrial engine is a 6-cylinders in line, 13.48 liter four-strokes engine with 114 mm bore and 135 mm stroke. DCECQSZ14 series Industrial engine equipped with Equipped with Electrically Control High-pressure Common Rail. The prime power range of is 460 HP to 560 HP.
To achieve different output, DCEC QSZ14 series Industrial engine have three configurations which are turbocharged engine, turbocharge with water-air intercooler, turbocharge with air-air intercooler. In the detailed model name, code T means engine come with turbocharger, code single A means engine comes with water-air intercooler, and code double A means engine comes with air-air intercooler. As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
DCEC QSZ14 series electronic industrial engine can reach upto EU Stage V emission standard, the number 30/40/50 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V. For different emission standard DCEC QSZ14 series electronic industrial engine, the engine itself are the same, the major different of different emission standard engine models are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard engine models, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.
General Specifications of QSZ14 Series
| Engine Type: | 6 Cylinders, in Line |
| Displacement: | 13.48 L |
| Rated Speed: | 2100 RPM |
| Emission Standards: | CH SG3 |
| Aspiration Method: | Turbocharged & CAC |
| Advertised Power: | 460 – 560 HP @ 2100 RPM |
| Peak Torque: | 2215 – 2400 N.m @ 1500 RPM |
| Bore * Stroke: | 114 mm * 135 mm |
| Wet Weight: | N/A |
| Dimension(L * W * H): | N/A |
Engine Model |
Rated Power |
Peak Torque |
Engine Model |
Rated Power |
Peak Torque |
||
| QSZ14-460-30 | 460 HP @ 2100 RPM | 2215 N.m @1500 RPM | QSZ14-490-30 | 490 HP @ 2100 RPM | 2200 N.m @1500 RPM | ||
| QSZ14-540-30 | 540 HP @ 2100 RPM | 2400 N.m @1500 RPM | QSZ14-560-30 | 560 HP @ 2100 RPM | 2400 N.m @1500 RPM | ||
| QSZ14-560-31 | 560 HP @ 2100 RPM | 2400 N.m @1500 RPM | |||||
| ——END—— | |||||||
DCEC QSZ14 Series Industrial Engine
All models of DCEC QSZ14 Series Industrial Engine.
Click here to find Industrial engines by type (Fuel System & Engine Speed).
QSZ14-C460-30 Industrial Engine
Rated Power: 460 HP @ 2100 RPM
Max. Torque: 2215 N.m @ 1500 RPM
Fuel System: HPCR
Aspiration: Turbocharged and Charge Air Cooled
Emission Standard: CH SG3
QSZ14-C490-30 Industrial Engine
Rated Power: 490 HP @ 2100 RPM
Max. Torque: 2200 N.m @ 1500 RPM
Fuel System: HPCR
Aspiration: Turbocharged and Charge Air Cooled
Emission Standard: CH SG3
QSZ14-C540-30 Industrial Engine
Rated Power: 540 HP @ 2100 RPM
Max. Torque: 2400 N.m @ 1500 RPM
Fuel System: HPCR
Aspiration: Turbocharged and Charge Air Cooled
Emission Standard: CH SG3
QSZ14-C560-30 Industrial Engine
Rated Power: 560 HP @ 2100 RPM
Max. Torque: 2400 N.m @ 1500 RPM
Fuel System: HPCR
Aspiration: Turbocharged and Charge Air Cooled
Emission Standard: CH SG3
QSZ14-C560-31 Industrial Engine
Rated Power: 560 HP @ 2100 RPM
Max. Torque: 2400 N.m @ 1500 RPM
Fuel System: HPCR
Aspiration: Turbocharged and Charge Air Cooled
Emission Standard: CH SG3
