DCEC L Automotive Engine
DCEC L series automotive engine is a 6-cylinders in line, 8.9 liter four-strokes engine with 114 mm bore and 135 mm stroke. Equipped with BYC (or Bosch or Weifu) pump, engine comes with turbocharger and Air- Air intercooler. The prime power range is from 300 HP to 375 HP.
As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, Dongfeng-DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
DCEC L series electronic automotive engine can reach upto EU Stage VI emission standard, the number 30/40/50/60 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V, VI. For different emission standard DCEC L electronic series automotive engine, the engine itself are the same, the major different are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.
General Specifications of L Series
| Engine Type: | 6 Cylinders |
| Displacement: | 8.9 L |
| Bore * Stroke: |
114 mm * 145 mm |
| Advertised Power: |
300 – 375 HP @ 2200 RPM |
| Peak Torque: |
1180 – 1480 N.m @ 1400 RPM |
| Rated Speed: | 2200 RPM |
| Emission Standards: |
Euro II |
| Aspiration Method: | Turbocharged & Intercooler |
| Wet Weight: | 650 kg |
| Dimension(L* W * H): | 1149 mm * 799 mm * 1022 mm |
Engine Model |
Rated Power |
Peak Torque |
Engine Model |
Rated Power |
Peak Torque |
||
| L300-20 | 300 HP @ 2200 RPM | 1180 N.m @ 1400 RPM | L325-20 | 325 HP @ 2200 RPM | 1230 N.m @ 1400 RPM | ||
| L340-20 | 340 HP @ 2200 RPM | 1350 N.m @ 1400 RPM | L340-30 | 340 HP @ 2200 RPM | 1350 N.m @ 1400 RPM | ||
| L360-20 | 360 HP @ 2200 RPM | 1480 N.m @ 1400 RPM | L360-30 | 360 HP @ 2200 RPM | 1480 N.m @ 1400 RPM | ||
| L375-30 | 375 HP @ 2200 RPM | 1480 N.m @ 1400 RPM | |||||
| ——END—— | |||||||
DCEC L Series Automotive Engine
This is the list of all series of DCEC L Series Automotive Engine.
Click here to find automotive engines by type (Fuel System & Emission Standard).
L300-20 Automotive Engine
Rated Power: 300 HP @ 2200 RPM
Max. Torque: 1180 N.m @ 1400 RPM
Fuel System: Bosch P7100 Pump
Aspiration: TC & Intercooler
Emission Standard: N/A
L325-20 Automotive Engine
Rated Power: 325 HP @ 2200 RPM
Max. Torque: 1230 N.m @ 1400 RPM
Fuel System: Bosch P7100 Pump
Aspiration: TC & Intercooler
Emission Standard: N/A
L340-20 Automotive Engine
Rated Power: 340 HP @ 2200 RPM
Max. Torque: 1350 N.m @ 1400 RPM
Fuel System: Bosch P7100 Pump
Aspiration: TC & Intercooler
Emission Standard: N/A
L340-30 Automotive Engine
Rated Power: 340 HP @ 2200 RPM
Max. Torque: 1350 N.m @ 1400 RPM
Fuel System: Weifu PH Pump
Aspiration: TC & Air-Air Intercooler
Emission Standard: N/A
L360-20 Automotive Engine
Rated Power: 360 HP @ 2200 RPM
Max. Torque: 1480 N.m @ 1400 RPM
Fuel System: Bosch P7100 Pump / RQV-K
Aspiration: TC & Intercooler
Emission Standard: N/A
L360-30 Automotive Engine
Rated Power: 360 HP @ 2200 RPM
Max. Torque: 1480 N.m @ 1400 RPM
Fuel System: Weifu PH Pump / RQV-K
Aspiration: TC & Air-Air Intercooler
Emission Standard: N/A
L375-30 Automotive Engine
Rated Power: 375 HP @ 2200 RPM
Max. Torque: 1480 N.m @ 1400 RPM
Fuel System: Bosch P7100 Pump / RQV-K
Aspiration: TC & Intercooler
Emission Standard: N/A
