DCEC ISF2.8 Automotive Engine
DCEC ISF2.8 automotive engine is a 4-cylinders in line, 2.8 liter four-strokes engine with 94 mm bore and 100 mm stroke. Equipped with Electrically Control High-pressure Common Rail, engine comes with turbocharger and Air- Air intercooler. The prime power range is from 130 HP to 150 HP.
As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, Dongfeng-DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
DCEC ISF2.8 series electronic automotive engine can reach upto EU Stage VI emission standard, the number 30/40/50/60 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V, VI. For different emission standard DCEC ISF2.8 electronic series automotive engine, the engine itself are the same, the major different are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.
General Specifications of ISF2.8 Series
| Engine Type: | 4 Cylinders |
| Displacement: | 2.8 L |
| Bore * Stroke: |
94 mm * 100 mm |
| Advertised Power: |
130 – 150 HP @ 3200 RPM |
| Peak Torque: |
150 – 310 N.m @ 1600 RPM |
| Rated Speed: | 3200 RPM |
| Emission Standards: |
Euro III -Euro VI |
| Aspiration Method: | Turbocharged & Intercooler |
| Wet Weight: | 213 kg |
| Fuel System: | Bosch Electronic |
Engine Model |
Rated Power |
Peak Torque |
Engine Model |
Rated Power |
Peak Torque |
||
| ISF2.8s3129T | 130 HP @ 3200 RPM | 310 N.m @ 1600 RPM | ISF2.8s4129T | 130 HP @ 3200 RPM | 310 N.m @ 1600 RPM | ||
| ISF2.8s4148T | 150 HP @ 3200 RPM | 150 N.m @ 1600 RPM | |||||
| ——END—— | |||||||
DCEC ISF2.8 Series Automotive Engine
This is the list of all series of DCEC ISF2.8 Series Automotive Engine.
Click here to find automotive engines by type (Fuel System & Emission Standard).
ISF2.8s3129T Automotive Engine
Rated Power: 130 HP @ 3200 RPM
Max. Torque: 310 N.m @ 1600 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air Intercooler
Emission Standard: Euro III
ISF2.8s4129T Automotive Engine
Rated Power: 130 HP @ 3200 RPM
Max. Torque: 310 N.m @ 1600 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air Intercooler
Emission Standard: Euro IV
ISF2.8s4148T Automotive Engine
Rated Power: 150 HP @ 3200 RPM
Max. Torque: 310 N.m @ 1600 RPM
Fuel System: Bosch Elec.
Aspiration: TC & Air Intercooler
Emission Standard: Euro IV
