DCEC 6CTA8.3-FP Pump Drive Engine
DCEC 6CTA8.3-FP series pump drive engine is a 6-cylinders in line, 8.3 liters four-strokes engine with 114 mm bore and 135 mm stroke. DCEC 6CTA8.3-FP series pump drive engine equipped with mechanical fuel pump and electronic governor. The prime power range for 1500 RPMof DCEC 6CTA8.3-FP series pump drive engine is from 151 kW to 194 kW. The prime power range for 1800 RPM of DCEC 6CTA8.3-FP series pump drive engine is from 151 kW to 194 kW.
DCEC pump drive engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. As part of EMAC, PumpMac provides abundant premium pump-driven power pack options, WPT PTO, Advance gearbox and pump head, as well as customized water pump set. We also have a set of NFPA20 standard engine power pack accessories including air intake shut-off valve, DC contactor, engine control panel, jacket water heater etc. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
DCEC 6CTA8.3-FP series electronic pump drive engine can reach upto EU Stage V emission standard, the number 30/40/50 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V. For different emission standard DCEC 6CTA8.3-FP series electronic pump drive engine, the engine itself are the same, the major different of different emission standard engine models are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard engine models, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.
General Specifications of 6CTA8.3-FP Series
| Engine Type: | 6 Cylinders, in Line |
| Displacement: | 8.3 L |
| Rated Speed: | 1500 – 3000 RPM |
| Rated Power / Speed: | 151 – 194 kW @ 1500 – 3000 RPM |
| Peak Torque: | 900 – 1165 N.m @ 1300 – 1800 RPM |
| Fuel System: | Weifu PW2000 / RSV Mechanical Governor |
| Aspiration Method: | TC & Water-Air Intercooler |
| Bore * Stroke: | 114 mm * 135 mm |
| Basic Engine(L * W * H): | 1159 mm * 734 mm * 1153 mm |
| Wet Weight: | 604 kg |
Engine Model |
Rated Power |
Peak Torque |
Engine Model |
Rated Power |
Peak Torque |
|
| 6CTA8.3-C205-II-FP | 151 kW @ 1850 RPM | 900 N.m @ 1400 RPM | 6CTA8.3-C215-II-FP | 160 kW @ 2200 RPM | 908 N.m @ 1500 RPM | |
| 6CTA8.3-P220-FP | 163 kW @ 1500 RPM | 1038 N.m @ 1500 RPM | 6CTA8.3-C225-FP | 166 kW @ 3000 RPM | N/A | |
| 6CTA8.3-P230-FP | 170 kW @ 1800 RPM | 902 N.m @ 1800 RPM | 6CTA8.3-C230-II-FP | 170 kW @ 1850 RPM | 1000 N.m @ 1400 RPM | |
| 6CTA8.3-C240-II-FP | 179 kW @ 2200 RPM | 1028 N.m @ 1500 RPM | 6CTA8.3-C260-II-FP | 194 kW @ 1900 RPM | 1150 N.m @ 1300 RPM | |
| 6CTAA8.3-C215-FP | 160 kW @ 2200 RPM | 980 N.m @ 1500 RPM | 6CTAA8.3-C240-FP | 179 kW @ 2200 RPM | 1040 N.m @ 1400 RPM | |
| 6CTAA8.3-C248-FP | 183 kW @ 3000 RPM | N/A | 6CTAA8.3-P250-FP | 183 kW @ 1500 RPM | 1165 N.m @ 1500 RPM | |
| 6CTAA8.3-P260-FP | 190 kW @ 1800 RPM | 1008 N.m @ 1800 RPM | 6CTAA8.3-C260-FP | 194 kW @ 2200 RPM | 1100 N.m @ 1400 RPM | |
| ——END—— | ||||||
DCEC 6CTA8.3-FP Series Pump Drive Engine
This list including all models of DCEC 6CTA8.3-FP Series Pump Drive Engine.
Click here to find pump engines by type (Fuel System & Engine Speed).
6CTAA8.3-C260-FP Pump Drive Engine
Rated Power: 194 kW @ 2200 RPM
Fuel Pump: BYC P7100
Governor: Mechanical
Aspiration: TC & Air-AirIntercooler
Emission Standard: Euro Stage II
6CTAA8.3-P260-FP Pump Drive Engine
Rated Power: 190 kW @ 1800 RPM
Fuel Pump: Mechanical
Governor: Electronical
Aspiration: TC & Air-Air Intercooler
Emission Standard: N/A
6CTAA8.3-P250-FP Pump Drive Engine
Rated Power: 183 kW @ 1500 RPM
Fuel Pump: Mechanical
Governor: Electronical
Aspiration: TC & Air-Air Intercooler
Emission Standard: N/A
6CTAA8.3-C248-FP Pump Drive Engine
Rated Power: 183 kW @ 3000 RPM
Fuel Pump: Mechanical
Governor:RSV Mechanical
Aspiration: Turbocharged & A-A Intercooled
Emission Standard: N/A
6CTAA8.3-C240-FP Pump Drive Engine
Rated Power: 179 kW @ 2200 RPM
Fuel Pump: BYC P7100
Governor: Mechanical
Aspiration: TC & Air-AirIntercooler
Emission Standard: Euro Stage II
6CTAA8.3-C215-FP Pump Drive Engine
Rated Power: 160 kW @ 2200 RPM
Fuel Pump: Weifu PW2000
Governor: Mechanical
Aspiration: TC & Air-AirIntercooler
Emission Standard: Euro Stage II
6CTA8.3-C260-II-FP Pump Drive Engine
Rated Power: 194 kW @ 1900 RPM
Fuel Pump: Weifu PW2000
Governor: Mechanical
Aspiration: TC & Water-AirIntercooler
Emission Standard: Euro Stage II
6CTA8.3-C240-II-FP Pump Drive Engine
Rated Power: 179 kW @ 2200 RPM
Fuel Pump: Weifu PW2000
Governor: Mechanical
Aspiration: TC & Water-AirIntercooler
Emission Standard: Euro Stage II
6CTA8.3-C230-II-FP Pump Drive Engine
Rated Power: 170 kW @ 1850 RPM
Fuel Pump: Weifu PW2000
Governor: Mechanical
Aspiration: TC & Water-AirIntercooler
Emission Standard: Euro Stage II
6CTA8.3-P230-FP Pump Drive Engine
Rated Power: 170 kW @ 1800 RPM
Fuel Pump: Mechanical
Governor: Electronical
Aspiration: TC & Water-AirIntercooler
Emission Standard: N/A
6CTA8.3-C225-FP Pump Drive Engine
Rated Power: 166 kW @ 3000 RPM
Fuel Pump: Mechanical
Governor:RSV Mechanical
Aspiration: Turbocharged & Intercooled
Emission Standard: N/A
6CTA8.3-P220-FP Pump Drive Engine
Rated Power: 163 kW @ 1500 RPM
Fuel Pump: Mechanical
Governor: Electronical
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
6CTA8.3-C215-II-FP Pump Drive Engine
Rated Power: 160 kW @ 2200 RPM
Fuel Pump: Weifu PW2000
Governor:RSV Mechanical
Aspiration: TC & Water-AirIntercooler
Emission Standard: Euro Stage II
6CTA8.3-C205-II-FP Pump Drive Engine
Rated Power: 151 kW @ 1850 RPM
Fuel Pump: Weifu PW2000
Governor:RSV Mechanical
Aspiration: TC & Water-AirIntercooler
Emission Standard: Euro Stage II
