6CTA8.3 Pump

DCEC 6CTA8.3 series pump drive engine is a 6-cylinders in line, 8.3 liters four-strokes engine with 114mm bore and 135mm stroke. DCEC 6CTA8.3 series pump drive engine equipped with mechanical fuel pump and electronic governor. The prime power range for 1500RPMof DCEC 6CTA8.3 series pump drive engine is from 163 kW to 183 kW. The prime power range for 1800RPM of DCEC 6CTA8.3 series pump drive engine is from 170 kW to 190 kW.

DCEC pump drive engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. As part of EMAC, PumpMac provides abundant premium pump-driven power pack options, WPT PTO, Advance gearbox and pump head, as well as customized water pump set. We also have a set of NFPA20 standard engine power pack accessories including air intake shut-off valve, DC contactor, engine control panel, jacket water heater etc. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

DCEC 6CTA8.3 series electronic pump drive engine can reach upto EU Stage V emission standard, the number 30/40/50 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V. For different emission standard DCEC 6CTA8.3 series electronic pump drive engine, the engine itself are the same, the major different of different emission standard engine models are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard engine models, welcome to subscribe our website to get latest update information.

If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.

Advantages of 6CTA8.3 Pump Drive Engine

1. Adopt Holset supercharger with integral wastegate valve, low speed response and strong power.
2. Good reliability The integrated design of cylinder block and cylinder head prevents water and oil leakage of the engine. There are 40% fewer parts than the same type of engine, and the failure rate is greatly reduced.
3. The overall cylinder design is adopted, the parts are about 25% less than similar products, the failure rate is less, and the maintenance is convenient.
4. The cylinder liner adopts plateau honing cross cover, corrosion-resistant high-nickel cast iron piston, which greatly reduces oil loss and improves durability and service life.
